Feature |
Effect |
Customer Benefit |
|
One-Piece Solid Construction |
No welded joints, zero segment loss risk, superior impact resistance |
Safer operation, no sudden blade failure, lower accident risk |
|
Alloy Tool Steel Grade |
Cr12MoV / SKD11 / D2 with high hardness HRC 58-63 and good toughness |
Long cutting life, resharpenable multiple times, lower cost per cut |
|
Precision Stamped & Ground |
Flatness ≤0.05mm, runout ≤0.03mm, smooth cutting with minimal vibration |
Clean cut surface, reduced material waste, extended machine spindle life |
|
Anti-Rust Surface Finish |
Polished / black oxide / painted surface resists corrosion during storage |
Longer shelf life, ready-to-use condition, less pre-use maintenance |
|
Diameter |
Thickness |
Arbor Hole |
Teeth |
Material |
Application |
|
100 - 160 |
1.0 - 2.0 |
16 / 20 / 25.4 |
30 - 60 |
Cr12MoV / SKD11 |
Soft wood, PVC, thin plastic |
|
180 - 250 |
1.5 - 2.5 |
25.4 / 30 / 32 |
48 - 100 |
Cr12MoV / D2 |
Hardwood, plywood, aluminum profile |
|
300 - 400 |
2.0 - 3.5 |
30 / 32 / 40 / 50 |
72 - 140 |
SKD11 / D2 |
Solid wood, MDF, copper bar, composite |
|
450 - 600 |
3.0 - 5.0 |
40 / 50 / 60 |
100 - 180 |
D2 / Custom |
Heavy timber, thick wall pipe, industrial cut-off |
* Custom tooth forms: TCG (triple chip grind), ATB (alternate top bevel), flat tooth, wavy tooth. Keyway and reduction rings available.
|
Woodworking & Furniture Solid wood, plywood, MDF, particle board cross-cutting & ripping Furniture frame cutting, door & window processing Decorative molding, flooring production line |
Non-Ferrous & Industrial Aluminum profile, copper bar, brass rod cut-off PVC pipe, PE/PP plastic profile cutting Fiberglass, carbon fiber composite trimming |
GEO Market Coverage：Our monolithic alloy saw blades are widely used by woodworking and metal processing customers in North America, Eastern Europe, Southeast Asia, South America and Africa. Compatible with table saws, miter saws, circular saws and automatic cut-off machines from major brands.
|
Customization Dimension |
Details |
|
Size & Dimension |
Custom diameter 80-800mm, thickness 0.8-8.0mm, any arbor hole size with keyway |
|
Tooth Geometry |
TCG, ATB, flat, wavy, custom hook angle (5°-20°) and top bevel angle |
|
Material Grade |
65Mn, 9CrSi, Cr12MoV, SKD11, D2, HSS M2 — matched to your cutting application |
|
Surface Treatment |
Mirror polish, black oxide, anti-rust paint, PVD coating (TiN/TiCN) |
|
Branding |
Laser marking or silk-screen printing of customer logo, size, tooth count & part number |
|
Packaging |
Individual plastic sleeve, color box, blister card, wooden crate for large diameters |
