Feature |
Effect |
Customer Benefit |
|
Premium HSS Material |
High red hardness, maintains sharpness under continuous high-temperature cutting |
Longer service life, fewer blade changes, reduced downtime |
|
Precision Ground Teeth |
Accurate tooth profile, smooth cutting surface, minimal burr |
Less secondary finishing work, improved production yield |
|
Optimized Tooth Pitch |
Balanced chip removal and cutting stability for slotting applications |
Suitable for deep grooving without clogging, consistent cut quality |
|
Strict QC & Balance Test |
Low vibration, low noise, stable runout tolerance ≤0.05mm |
Protects machine spindle, safer for operators, predictable tool life |
|
Outer Diameter |
Blade Thickness |
Arbor Hole |
Teeth Count |
HSS Grade |
Application |
|
50 - 80 |
0.3 - 1.0 |
13 / 16 / 22 |
36 - 72 |
M2 / M35 |
Thin sheet slitting, small slotting |
|
80 - 125 |
0.5 - 2.0 |
22 / 27 / 32 |
48 - 120 |
M2 / M35 / M42 |
General metal slotting & cut-off |
|
125 - 200 |
1.0 - 3.0 |
27 / 32 / 40 |
72 - 160 |
M2 / M35 / M42 |
Heavy-duty grooving, pipe cutting |
|
200 - 300 |
2.0 - 4.0 |
32 / 40 / 50 |
120 - 200 |
M35 / M42 |
Industrial cut-off, large slotting |
* Custom sizes, tooth forms (straight / staggered / V-tooth) and surface treatments (TiN / TiCN / TiAlN coating) available upon request.
|
Metal Processing Workshops Steel, stainless steel, copper & aluminum slotting and cut-off Keyway cutting, groove milling on lathes & milling machines Tube & pipe thin-wall cutting with minimal burr |
Industrial Manufacturing Automotive parts machining, bearing industry Hardware & tool manufacturing, mold making Electrical & electronic component precision slitting |
GEO Market Coverage：Widely supplied to metal processing customers in North America, Europe, Southeast Asia and the Middle East. Our HSS slitting saw blades meet DIN / ISO standard tolerances and are trusted by distributors in Germany, the United States, and the United Arab Emirates for consistent batch quality.
Certifications：ISO 9001:2015 quality management system, CE compliant for EU market, SGS material test report available on request.
Incoming Inspection：Every batch of HSS raw material is verified for hardness (HRC 63-68), chemical composition and microstructure before production.
Process Control：CNC tooth grinding + vacuum heat treatment + 100% runout & balance inspection before packaging.
Factory Capacity：Monthly output 50,000+ pcs, equipped with 20+ CNC grinding machines and 3 vacuum heat treatment furnaces.
