Feature |
Effect |
Customer Benefit |
|
Precision Lapped Edge |
Mirror-finish cutting edge with Ra ≤0.2μm, zero burr on slit edge |
Higher slitting quality, reduced material waste, less rewind rejection |
|
Premium Steel Grades |
9CrSi, Cr12MoV, HSS M2, SKD11, tungsten carbide options |
Right material for each application, optimized cost-performance ratio |
|
Tight Tolerance Control |
Outer diameter ±0.01mm, thickness ±0.005mm, runout ≤0.003mm |
Consistent slit width, stable knife gap, fewer line adjustments |
|
Matched Top & Bottom Set |
Top slitter knife & bottom ring engineered as a pair for optimal shear cut |
Longer blade life, cleaner cut, lower per-meter slitting cost |
|
Blade Type |
Outer Diameter |
Inner Diameter |
Thickness |
Material |
Typical Use |
|
Top Slitter Knife |
60 - 150 |
25.4 / 40 / 50 / 60 |
0.5 - 3.0 |
SKD11 / HSS / Carbide |
Film, foil, paper slitting |
|
Bottom Ring Knife |
80 - 200 |
40 / 50 / 60 / 80 |
2.0 - 10.0 |
Cr12MoV / SKD11 |
Shear cut bottom support |
|
Score Cut Blade |
50 - 120 |
25.4 / 32 / 40 |
1.0 - 5.0 |
HSS M2 / Carbide |
Tape, label, nonwoven |
|
Circular Shear Blade |
100 - 300 |
40 / 50 / 60 / 80 |
2.0 - 8.0 |
9CrSi / Cr12MoV |
Metal sheet, tube slitting |
* All dimensions customizable per drawing. Surface treatments: polished, TiN coated, TiAlN coated, chrome plated.
|
Customization Dimension |
Details |
|
Dimensions |
Any OD, ID, thickness within machine range; provide drawing or sample for replication |
|
Material |
9CrSi, Cr12MoV, SKD11, D2, HSS M2/M35, powder steel, tungsten carbide (YG8/YG10X) |
|
Edge Geometry |
Single bevel, double bevel, concave, razor edge — angle 15°-45° per material |
|
Surface Treatment |
Mirror polish, TiN/TiCN/TiAlN/DLC coating, chrome plating, black oxide |
|
Branding & Packaging |
Laser engraved logo & part number; wooden case, plastic box, anti-rust paper packaging |
A: We do not offer free samples. Circular cutting blade samples involve specialized raw materials (high-grade steel body and precision-ground cutting teeth) and require dedicated small-batch production setup, making the per-unit cost significantly higher than mass production. The sample fee covers material, production, and international shipping costs. However, if you proceed to place a bulk order (≥500 pcs), the sample fee can be deducted from your final order payment. Sample production typically takes 5–7 working days, and we provide a test cutting video before shipment.
A: 30% advance deposit (T/T) upon order confirmation · 70% balance payment before shipment (after production completion and quality inspection). For long-term partners and agent distributors, we can negotiate L/C (Letter of Credit) at sight. All terms are stated in the Proforma Invoice (PI) and formal Sales Contract.
A: Payment Methods: T/T, L/C, D/P, D/A, MoneyGram, Credit Card, PayPal, Western Union, Cash. Currencies: USD (US Dollar), EUR (Euro). Incoterms 2020: FOB, CFR, CIF, EXW. For orders exceeding USD 50,000, L/C at sight provides additional security under ICC UCP 600.
A: Structured after-sales claim process:
Report: Contact within 15 days of receipt. Provide photos/videos, batch number, cutting application details.
Analysis: R&D engineers analyze within 48 hours.
Solution: Manufacturing defect → free replacement in next shipment. Application mismatch → recommend correct blade model.
Compensation: Full replacement or credit per Sales Contract terms.
